Name: China Good Price Al2O3-SiC-C Brick Manufacturers Suppliers Factory - Customized Service
Brand: Topower
SKU: 197864364

Al2O3-SiC-C Brick is made of fused corundum (or sintered corundum, special grade bauxite clinker), graphite and silicon carbide with fixed carbon above 90%-95% as the main raw materials.
MOQ: 5 tons

Send Inquiry

Product Introduction

Description

Al2O3-SiC-C Brick, referred to as ASC brick. It is made by adding graphite, bauxite, and additives, after batching, forming, drying and high temperature firing. ASC brick has very good high temperature performance and anti-oxidation, anti-flaking and anti-slag erosion properties, can withstand long-term high-temperature solution erosion, and has a long service life.

Al2O3-SiC-C bricks blend high-purity alumina (Al2O3), silicon carbide (SiC), and carbon (C) as the primary raw materials. Alumina ensures high refractoriness and chemical stability, while silicon carbide enhances thermal conductivity and abrasion resistance. Carbon content optimizes thermal shock resistance and corrosion resilience.

Al2O3-SiC-C Brick is mainly used as sliding nozzle slide, continuous casting tundish integral stopper, etc. It can also be used as lining for hot metal pretreatment and steel ladle lining. According to different manufacturing processes, aluminum carbon bricks can be divided into fired aluminum carbon bricks and unfired aluminum carbon bricks.

Fired aluminum-carbon bricks are ceramic bonding or ceramic-carbon composite bonding materials. They are widely used as sliding nozzle slides, long nozzles, immersion nozzle upper and lower nozzle bricks and integral stoppers for continuous casting. Unburned aluminum-carbon bricks are carbon-bonded materials. Because their oxidation resistance is significantly better than that of magnesia-carbon bricks and the corrosion resistance of Na2O slag is excellent, they have been widely used in hot metal pretreatment equipment.

Features

Exceptional Thermal Stability: Al2O3-SiC-C bricks exhibit superior thermal resistance, maintaining structural integrity at extreme temperatures, surpassing traditional refractories.
Enhanced Mechanical Strength: The combination of Al2O3, SiC, and C provides remarkable mechanical durability, reducing wear and ensuring longer service life in harsh environments.
Resistance to Thermal Shock: The presence of carbon contributes to superior thermal shock resistance, crucial for applications involving rapid temperature changes.
Excellent Corrosion and Erosion Resistance: These bricks withstand corrosive and erosive elements, making them ideal for aggressive industrial settings.
Low Porosity: The low porosity characteristic ensures minimal heat loss and excellent insulation properties.

Al2O3-SiC-C

Application

Al2O3-SiC-C Brick is one of the commonly used refractory materials for thermal equipment used in the hot metal pretreatment stage, especially in the hot metal tank, the usage rate is very high. Widely used in the steel industry.

Physical And Chemical Indicators

Al2O3-SiC-C Brick Properties		TC SZ	TC MZ	TC BI	TC TR
Apparent Porosity (%)		7	8	8	9
Bulk Density (g/cm3)		3.00	2.98	2.98	2.93
Cold Crushing Strength (MPa)		55	50	45	45
Thermal Linear Expansion(%) @ 1,000℃		0.58	0.55	0.55	0.52
Refractoriness Under Load (℃) @0.2MPa		1750	1700	1700	1650
Chemical Analysis (%)	Al2O3	72	68	67	65
	SiC	11	10	10	10
	FC	13	12	11	10
Main Applications		Torpedo & Iron Ladle

Productive Process

1.Raw material quality control including physical and chemical testing.
2.Crushing and grinding of bulk raw materials.
3. According to customer data sheet required to mixing Raw Material.
Pressing or shaping the green brick depend on different raw material and brick shape.
4.Dry the bricks at dryer kiln.
5.Put the bricks into the tunnel kiln to burning by higher temp from 1300-1800 deg.
6.The quality control department will inspect the finished refractory bricks random.

product-750-487

FAQ

Q: How can you control your Al2O3-SiC-C bricks quality?

A: TOPOWER have complete QC system for the chemical composition and Physical properties. After magnesia ziron bricks production, all the goods will be tested, and the quality certificate will be shipped along with goods.

Q: How to package for Al2O3-SiC-C Brick ?

A: Packaging according to safety sea-exporting packing Standard Dispatch : loading the finished packing material at factory by container Door toDoor By sea fumigated wooden pallet + plastic belt + plastic film wrap
