Fire Brick

Fire brick is made of 50% soft clay and 50% hard clay clinker, which are batched according to certain particle size requirements. After molding and drying, they are fired at a high temperature of 1300~1400℃.
MOQ:5 tons
Send Inquiry
Product Introduction
Description



Fire brick is weakly acidic refractory product, which can resist the erosion of acidic slag and acid gas, and have a slightly weaker resistance to alkaline substances, good thermal performance, and resistance to rapid cold and heat

One of the most common types of products from the silica-alumina series is fireclay brick. They are formed of refractory clay as the binder and clay clinker as the aggregate and are refractory materials products with a 30–48% Al2O3 concentration.

Al2O3 percentage in fire brick produced in China typically exceeds 40%, whereas Fe2O3 level ranges between 2.0 and 2.5%. Between 65 and 85% of the constituents are clinker, and between 35 and 15% are clay. In order to create a semi-dry mud that can be more effectively molded under high pressure and burnt at approximately 1400°C, the combined crushed clay and the finely ground clinker are blended and pulverized before being combined with the granular clinker.The ability of fire brick to withstand alkaline slag erosion is marginally worse at high temperatures because it is weakly acidic, but it improves as the Al2O3 percentage rises. In comparison to magnesia and silica bricks, the thermal stability is superior.



Features



The specific characteristics of fire brick include:

Good high temperature fire resistance under load / Low thermal expansion at high temperatures

Lower impurity content / Good thermal shock resistance

Excellent slag and abrasion resistance / Good cold press strength

clay bricks





Application



Thermal boilers, glass kilns, cement kilns, fertilizer gas furnaces, hot blast furnaces, coking furnaces, electric furnaces, bricks for casting and pouring steel, etc. all use fire brick extensively.



application





Physical And Chemical Indicators

Brand
Properties

SK-32

SK-33

SK-34

SK-35

Refractoriness (SK)

32

33

34

35

 Apparent Porosity (%)

26

24

23

23

 Bulk Density (g/cm3)

2.10

2.15

2.20

2.25



Cold Crushing Strength (MPa)

20

30

35

40

@ 1,000℃

Thermal Linear Expansion(%)

0.6

0.6

0.6

0.6

@ 1350℃ x 2hrs

Permanent Linear Change (%)

±0.5

±0.5

±0.3

±0.3

 @0.2MPa

Refractoriness Under Load (℃)

1,250

1,300

1,350

1,380



Chemical

Composition (%)

Al2O3

35

38

40

46

Fe2O3

3.0

2.2

2.0

2.0



Main Applications

Coke Oven

 Incinerator

Glass Furnace

Various Rotary Kiln

 Reheating Furnace

Chemical Reactor

Blast Furnace,

Torpedo Car

Non Ferrous Metal Furnace

 General Industrial Furnace etc.
